Roughly

Organic, hand-drawn vector annotations designed for high-friction digital typography. Wobbly underlines, pen circles, editorial strikethroughs, curly brackets, and tactile highlights.

$pnpm dlx shadcn@latest addhttps://void-ui.vercel.app/r/roughly.json

Scroll

Interactive Playground

Annotation Type9 styles

Sample Text

Underline Style

Color Presets

Stroke Width2.5px

Duration750ms

Live Canvas

Interfaces with visceral depth

React Component Snippet

1<RoughUnderline strokeWidth={2.5}>

2 Interfaces with visceral depth

3</RoughUnderline>

Editorial Typography Demonstration

Void UI components are designed with tactile physical friction, transforming sterile digital surfaces into visceral instruments. Rather than flattening user interfaces, we introduce deliberate resistance and dynamic spring dynamics.

In traditional software development, designers often rely on bland grey boxes and lifeless borders. With Roughly, you can draw attention to critical insights or mark deprecated features with an organic cross out.

• Zero layout shift on page reloads

• Sized to encompass all tall ascenders and low descenders

• Scroll-triggered hardware-accelerated SVG draw animation

Every annotation is enclosed in a hand-drawn rough frame with natural corner overshoots and fluid double stroke sketch loops.

Direct the reader's gaze with an expressive Direct vector pointing ✨hand-drawn callout arrow that automatically calculates its trajectory, clearance, and entry angle directly onto the target word.

How to Use

Install via Void UI CLI

Add Void UI's Roughly annotations directly into your project via the shadcn CLI. This downloads the source code into components/ui/roughly/ and automatically resolves all peer dependencies.

$pnpm dlx shadcn@latest add https://void-ui.vercel.app/r/roughly.json

Import Components

Import the individual annotation subcomponents from your local UI directory for optimal tree-shaking, or use the unified compound <Roughly> component.

Named Imports

1import {

2 Roughly,

3 RoughCircle,

4 RoughUnderline,

5 RoughHighlight,

6 RoughBox,

7 RoughBracket,

8 RoughStrike,

9 RoughCross,

10 RoughArrow,

11} from "@/components/ui/roughly";

Annotate Text & Keywords

Wrap any word, phrase, or inline block. Annotations automatically measure bounding boxes and draw with organic hand-drawn roughness when scrolled into view.

Example Component

1import {

2 RoughHighlight,

3 RoughCircle,

4 RoughUnderline,

5 RoughBox,

6} from "@/components/ui/roughly";

8export default function ArticleHero() {

9 return (

10 <div className="space-y-4">

11 {/* Tactile Marker Highlight */}

12 <h1 className="text-3xl font-bold text-white">

13 Design with <RoughHighlight color="#4338CA">physical friction</RoughHighlight>

14 </h1>

16 {/* Hand-drawn Pen Circle */}

17 <p className="text-neutral-300">

18 Focus on <RoughCircle color="#6366F1">critical insights</RoughCircle> inside body copy.

19 </p>

21 {/* Wavy Underline */}

22 <p className="text-neutral-300">

23 Add energy with <RoughUnderline variant="wavy" color="#10B981">expressive underlines</RoughUnderline>.

24 </p>

26 {/* Sketch Box Frame */}

27 <p className="text-neutral-300">

28 Enclose cards in a <RoughBox color="#F59E0B" variant="double">hand-drawn frame</RoughBox>.

29 </p>

30 </div>

31 );

32}

Expressive Callout Arrows

Wrap any CTA button or keyword with <RoughArrow> to anchor an arrow with dynamic curve trajectories and handwritten callout notes.

Arrow Callout

1import { RoughArrow } from "@/components/ui/roughly";

3export function CalloutDemo() {

4 return (

5 <div className="p-12 flex justify-center">

6 <RoughArrow

7 placement="top-right"

8 variant="curved"

9 arrowhead="open"

10 color="#F59E0B"

11 label="Interactive Studio ✨"

12 labelFont="caveat"

13 distance={65}

14 >

15 <button className="px-6 py-3 rounded-xl bg-white text-black font-semibold shadow-lg">

16 Launch Console

17 </button>

18 </RoughArrow>

19 </div>

20 );

21}

Handwritten Callout Fonts Setup

To use handwriting script for callouts ("caveat", "reenie-beanie", or "kalam"), load Google Fonts in your root layout:

app/layout.tsx

1<head>

2 <link

3 rel="stylesheet"

4 href="https://fonts.googleapis.com/css2?family=Caveat:wght@500;700&family=Kalam:wght@300;400;700&family=Reenie+Beanie&display=swap"

5 />

6</head>

API Reference

Prop	Type	Default	Description
type	RoughlyType	"underline"	"underline" \| "circle" \| "strike-through" \| "cross-off" \| "bracket" \| "box" \| "highlight" \| "arrow" \| "handwriting"
color	string	Preset by type	Any valid CSS color string (Hex, RGB, HSL)
strokeWidth	number	2	Thickness of pen strokes in pixels
animate	boolean	true	Triggers pen stroke drawing on scroll viewport entry
animationDuration	number	650	Duration of drawing in milliseconds
side / brackets	BracketSide	"left"	"left" \| "right" \| "both" \| "top" \| "bottom" (for bracket type)
bracketStyle	BracketStyle	"curly"	"curly" ({ }) \| "square" ([ ])
variant	string	"single"	"single" \| "double" \| "wavy" (underline) • "single" \| "double" \| "triple" (strike) • "single" \| "double" (cross & box)
iterations	number	2	Number of stroke passes (e.g. 2 for double strokes in box, arrow, highlight, and circle)
placement	ArrowPlacement	"top-right"	Direction from which the arrow points at the target: "top-left" \| "top" \| "top-right" \| "right" \| "bottom-right" \| "bottom" \| "bottom-left" \| "left"
arrowVariant / variant	ArrowVariant	"curved"	Curve trajectory: "curved" (parabolic arc) \| "s-curve" (double wave) \| "straight"
arrowhead	ArrowheadStyle	"open"	Style of arrow tip: "open" (>) \| "filled" (solid triangle)
label	ReactNode	undefined	Handwritten callout text displayed at the tail of the arrow
labelFont	ArrowLabelFont	"caveat"	Handwriting font family for callout text: "caveat" (default) \| "reenie-beanie" \| "kalam"
labelFontSize	number	20 \| 26	Font size in pixels for handwritten callout text
labelPlacement	ArrowLabelPlacement	"auto"	Placement relative to arrow tail: "auto" \| "top" \| "bottom" \| "left" \| "right"
labelDistance	number	8	Gap distance in pixels between arrow tail and label
labelRotate	number	0	Custom label rotation angle in degrees
labelOffsetX / labelOffsetY	number	0	Fine-tuning pixel nudges along X and Y axes
labelColor	string	color	Custom color override for the callout text (defaults to arrow color)
curveLabel	boolean	true	When true, renders callout text along a smooth mathematical SVG arc with zero misalignment
font	HandwritingFont	"reenie-beanie"	Font family for handwriting type: "reenie-beanie" (default) \| "caveat" \| "kalam"
fontSize	number	40	Font size in pixels used to generate handwriting glyph paths
editable	boolean	false	Enables interactive live-typing mode for handwriting with real-time SVG stroke tracing
